Product Overview
DN 20–110mm, PN 12.5/16, red/orange color. Thick-wall high-impact UPVC for high-pressure pump outlets and demanding irrigation systems.
Quick Information
- Diameter Range: DN 20 – 110 mm
- Pressure Rating: PN 12.5, PN 16 (High-Strength Grade)
- Material: High-Impact UPVC (UV Stabilized)
- Color Options: Red, Orange (Custom colors on request)
- Applicable Standards: GB/T 10002.1, ISO 1452
- Stock Availability: In stock
Specification Table
| DN (mm) | OD (mm) | Wall Thickness (mm) | Length (m) |
|---|---|---|---|
| 20 | 20.0 | 2.0 | 4 |
| 25 | 25.0 | 2.5 | 4 |
| 32 | 32.0 | 2.8 | 4 |
| 40 | 40.0 | 3.0 | 4 |
| 50 | 50.0 | 3.5 | 4 / 6 |
| 63 | 63.0 | 4.5 | 4 / 6 |
| 75 | 75.0 | 5.2 | 4 / 6 |
| 110 | 110.0 | 7.5 | 6 |
