HDPE Socket Fusion 45° Elbow for Water

HDPE socket fusion 45° elbow for water supply, injection molded for reliable fusion joints.

Extra Valuable Service
✧High Quality: ISO Certified Quality ✧Global Transportation Service
✧Free samples& Free Design ✧Full Satisfaction Guaranteed: 5-Year Guarantee

Category: HDPE Butt Fusion Fittings

HDPE Butt Fusion Fittings

Product Overview

HDPE socket fusion 45° elbow for water supply, injection molded for reliable fusion joints. This HDPE socket fusion 45-degree elbow is molded from PE100 resin in sizes 20 to 110 mm, rated PN10 to PN25 under ISO 4427 and EN 12201. The gentle 45° change of direction cuts head loss and water hammer compared with right-angle turns.

Quick Information

Type: 45° Elbow
Material: HDPE PE100
Size: 20 - 110 mm
Pressure: PN25 / PN20 / PN16 / PN10
Standard: ISO 4427 / EN 12201
Stock: In stock

Specification Table

SPECIFICATION (dn)	L	H	SDR17	SDR13.6	SDR11
L50X45°	150	55	√		√
L63X45°	160	63	√		√
L75X45°	185	70	√		√
L90X45°	228	79	√		√
L110X45°	265	82	√		√
L125X45°	250	87	√		√
L140X45°	270	92	√		√
L160X45°	305	98	√		√
L180X45°	340	105	√		√
L200X45°	355	112	√		√
L225X45°	398	120	√		√
L250X45°	420	129	√		√
L280X45°	485	139	√		√
L315X45°	510	150	√		√
L355X45°	550	164	√		√
L400X45°	600	179	√		√
L450X45°	560	130	√		√
L500X45°	610	135	√		√
L560X45°	650	135	√		√
L630X45°	710	145	√		√
L710X45°	835	180	√		√
L800X45°	900	180	√		√

Key Features

Gentle 45-Degree Flow Path: The HDPE socket fusion 45° elbow turns flow gradually, lowering friction loss and surge pressure in pumped water lines.
Precision Socket Geometry: Both sockets of the socket fusion 45° elbow hold depth and taper within tight tolerance for full-strength fusion joints.
PE100 Raw Material: Each HDPE socket fusion 45-degree elbow is molded from virgin PE100 resin for high hydrostatic strength and impact resistance.
Leak-Free Homogeneous Joints: The socket fusion 45° elbow welds into a single body with the pipe, eliminating gaskets and future leak points.
Corrosion and Scale Free: An HDPE 45° elbow never rusts or scales, keeping its smooth bore for a 50-year design life.
Pair for Offset Bends: Two HDPE socket fusion 45° elbows combine into a smooth offset to clear obstacles in trenches and plant rooms.

Production

Raw Material

Every HDPE socket fusion 45° elbow is molded from certified virgin PE100 resin with carbon black UV stabilizer, batch-tested for melt flow rate and density.

Molding Process

Each socket fusion 45-degree elbow is injection molded with angled core pins that form both sockets in one cycle, holding the 45° angle within 0.5 degrees.

Quality Control

Batches of HDPE socket fusion 45° elbows are sampled for hydrostatic pressure tests at 20 and 80 degrees C, angle verification and socket depth gauging per ISO 4427 and EN 12201.

Applications

Municipal water networks use the HDPE socket fusion 45° elbow for gentle direction changes at road crossings and valve chambers.
Building water systems install this socket fusion 45-degree elbow on risers and ceiling runs to reduce pump load.
Agricultural irrigation relies on the HDPE socket fusion 45° elbow to follow field contours with minimal head loss.
Industrial plants choose the socket fusion 45° elbow for offset piping around equipment and structural steel.
