HDPE Floating Dredging System

HDPE Floating Dredging System, to ISO 4427 (pipe), custom floater design, for dredging and floating pipeline projects.

Extra Valuable Service
✧High Quality: ISO Certified Quality ✧Global Transportation Service
✧Free samples& Free Design ✧Full Satisfaction Guaranteed: 5-Year Guarantee

Category: HDPE Pipes

HDPE Pipes

Product Overview

DN 100–500mm floating pipeline system combining HDPE dredging pipe with high-buoyancy HDPE floaters. Ideal for river, lake, and marine dredging, sludge discharge, and offshore pumping. Floater buoyancy 90–1350 kg per pair. Each HDPE floating dredging pipe section is engineered as a complete buoyant module, keeping the slurry line afloat under full load while the orange floaters stay visible on the water surface.

Quick Information

Pipe Diameter: DN 100 – 500 mm
Floater ID: 130 – 530 mm
Net Buoyancy: 90 – 1350 kg per pair
Material: HDPE PE100 Pipe + HDPE/PE Foam Floaters
Floater Color: Orange (high-visibility)
Joint Type: Butt Fusion Pipe + Steel Flange (optional)
Standard: ISO 4427 (pipe), custom floater design
Stock Availability: Made to order

Specification Table (Floater)

Pipe DN (mm)	Floater ID (mm)	Floater OD (mm)	Length (mm)	Net Buoyancy (kg/pair)
100	130	500	500	90
180	210	600	800	300
225	260	700	900	350
250	280	700	900	410
300	320	1000	1000	500
350	380	1100	1100	550
400	430	1200	1200	1200
500	530	1300	1500	1350

Key Features

High Buoyancy Design: Foam-filled or air-chamber floaters keep the HDPE floating dredging pipe afloat under full slurry load.
High-Visibility Orange: Marine-grade UV-stabilized orange floaters stay bright for safe navigation around the floating line.
Abrasion & Corrosion Resistant: The HDPE floating dredging pipe resists slurry wear, saltwater and chemicals in marine service.
Quick Assembly: Segmented HDPE floating dredging pipe plus bolted floater clamps allow fast on-site installation and relocation.
Flexible & Durable: The HDPE floating dredging pipe withstands waves, currents and thermal movement without cracking.
Wide DN 100 – 500 Range: Eight floater sizes match the HDPE floating dredging pipe diameter with 90 to 1350 kg net buoyancy per pair.

Production

Raw Material

The HDPE floating dredging pipe is extruded from certified PE100 black compound per ISO 4427, while floaters are molded from HDPE shell with PE foam or air-chamber filling.

Assembly Process

PE100 pipe sections are butt-fusion welded into continuous floating lengths, then matched with precision-molded floaters and locating clamps.

Quality Control

Each HDPE floating dredging pipe floater is buoyancy-tested to guarantee net lift, and pipe welds are inspected for fusion integrity before delivery.

Applications

River and lake dredging slurry discharge lines use the HDPE floating dredging pipe for afloat slurry transport.
Marine sand and gravel pumping operations rely on the HDPE floating dredging pipe for stable offshore discharge.
Offshore dewatering and discharge pipelines install the HDPE floating dredging pipe as a quick-deploy floating line.
Port, harbor and land reclamation projects choose the HDPE floating dredging pipe for visible, relocatable slurry routing.
