HDPE Square Pipe Clip for Siphonic Drainage

A square pipe clip manufactured from high-density polyethylene, specifically designed for fixing and supporting square rainwater pipes in siphonic systems.

Extra Valuable Service
✧High Quality: ISO Certified Quality ✧Global Transportation Service
✧Free samples& Free Design ✧Full Satisfaction Guaranteed: 5-Year Guarantee

Category: HDPE Siphonic Fittings

HDPE Siphonic Fittings

Product Overview

A square pipe clip manufactured from high-density polyethylene, specifically designed for fixing and supporting square rainwater pipes in siphonic systems. This HDPE square pipe clip secures square downpipes from 30x30 to 200x200 mm on horizontal and vertical runs, holding alignment under full-bore siphonic flow while allowing thermal movement. Enterprise standard quality for siphonic roof drainage support.

Quick Information

Diameter Range: 30*30 - 200*200 mm square pipe
Applicable Standards: Enterprise Standard
Stock: In stock

Specification Table

Parameter	Specification
Material	HDPE PE100
Pipe Size	3030 - 200200 mm square
Application	Siphonic Drainage Pipe Support
Standard	ISO 4427
Stock	In stock

Key Features

Full Square Size Range: The HDPE square pipe clip covers 30x30 to 200x200 mm square pipe, one clip family for the whole siphonic project.
Secure Under Siphonic Flow: This siphonic pipe clip grips pipe against the vibration and negative pressure of full-bore siphonic discharge.
PE100 Durability: The HDPE square pipe clip resists impact, UV and rooftop chemicals, outlasting metal clips without rust.
Thermal Movement Allowance: This siphonic pipe clip holds the pipe firmly yet permits the axial movement HDPE needs under temperature change.
Vibration Damping: The HDPE square pipe clip isolates flow vibration from the structure, keeping siphonic systems quiet.
Corrosion Free: This siphonic pipe clip never rusts or needs painting, ideal for exposed roofs and humid shafts.

Production

Raw Material

Every HDPE square pipe clip is molded from certified virgin PE100 resin with carbon black UV stabilizer, batch-tested for melt flow rate and density.

Molding Process

Each siphonic pipe clip is injection molded with spring-grip jaws sized per pipe dimension, holding dimensional tolerance within 0.1 mm.

Quality Control

Batches of HDPE square pipe clips are sampled for pull-out load testing, dimensional gauging and fatigue cycling before dispatch.

Applications

Siphonic roof drainage systems use the HDPE square pipe clip to fix square collectors along roof spans.
Vertical rainwater stacks rely on this siphonic pipe clip for rigid support at every floor.
Industrial plants install the HDPE square pipe clip where corrosive air destroys metal fasteners.
Commercial buildings choose this siphonic pipe clip for maintenance-free pipe fixing.
