Product Overview
The geotextile sand bag from Bingo Pipeline is a sand-filled container made of PET or PP thermo-calendered nonwoven fabric. With 1600 N CBR puncture resistance and 9 - 16 kN/m tensile strength, the geotextile sand bag withstands wave impact and abrasion while allowing water to drain through the fabric.
Standard bag sizes are 1.03 x 0.7 m and 1.03 x 0.6 m in 200 g/m² or 300 g/m² fabric, and the geotextile sand bag can be supplied in custom dimensions and colours for specific coastal or riverbank layouts.
Quick Information
- Material: PET / PP thermo-calendered nonwoven
- Mass per unit area: 200 or 300 g/m²
- Tensile strength (MD/CD): 9 / 11.5 / 16 kN/m
- Elongation at break: >50 %
- Grab strength: 625 / 625 N
- Trapezoidal tear: 280 N
- CBR puncture: 1600 N
- Bag size: 1.03 x 0.7 m / 1.03 x 0.6 m, customized
Specification Table
| Property | Specification |
|---|---|
| Material | PET / PP thermo-calendered nonwoven |
| Mass per unit area | 200 g/m² or 300 g/m² |
| Tensile strength (MD / CD) | 9 / 11.5 / 16 kN/m |
| Elongation at break (MD / CD) | >50 / 50 % |
| Grab strength (MD / CD) | 625 / 625 N |
| Trapezoidal tear strength (MD / CD) | 280 N |
| Static puncture strength (CBR) | 1600 N |
| Bag dimension (L x W) | 1.03 x 0.7 m / 1.03 x 0.6 m, customized |
| Colour | Green, grey, black or as requested |
