HDPE 30*30 Vertical Pipe Clip for Siphonic Drainage

A 30*30 vertical pipe clip manufactured from high-density polyethylene, used for hanging and securing suspended pipes in siphonic drainage systems.

Extra Valuable Service
✧High Quality: ISO Certified Quality ✧Global Transportation Service
✧Free samples& Free Design ✧Full Satisfaction Guaranteed: 5-Year Guarantee

Category: HDPE Siphonic Fittings

HDPE Siphonic Fittings

Product Overview

A 30*30 vertical pipe clip manufactured from high-density polyethylene, used for hanging and securing suspended pipes in siphonic drainage systems. This HDPE 30x30 vertical pipe clip grips 30x30 mm square downpipes on vertical runs, locking alignment and transferring load to the structure while allowing thermal movement. Enterprise standard quality for siphonic roof drainage support.

Quick Information

Diameter Range: For 30*30 mm square pipe or corresponding round pipe
Applicable Standards: Enterprise Standard
Stock: In stock

Specification Table

Specification
DN50
DN63
DN75
DN90
DN110
DN125
DN160
DN200
DN250
DN315

Key Features

Precision 30x30 Fit: The HDPE 30x30 vertical pipe clip is sized exactly for 30x30 mm square downpipes, holding alignment on vertical siphonic runs.
Secure Vertical Support: This siphonic drainage clip transfers the weight of water-filled vertical pipe to the structure without slip.
PE100 Durability: The HDPE 30x30 vertical pipe clip resists impact, UV and chemicals, outlasting metal clips without rust.
Thermal Movement Allowance: This siphonic drainage clip holds the pipe firmly yet permits axial expansion and contraction.
Vibration Damping: The HDPE 30x30 vertical pipe clip isolates flow vibration from the structure, keeping siphonic stacks quiet.
Corrosion Free: This siphonic drainage clip never rusts or needs painting, ideal for shafts and exposed risers.

Production

Raw Material

Every HDPE 30x30 vertical pipe clip is molded from certified virgin PE100 resin with carbon black UV stabilizer, batch-tested for melt flow rate and density.

Molding Process

Each siphonic drainage clip is injection molded with spring-grip jaws sized for 30x30 mm pipe, holding dimensional tolerance within 0.1 mm.

Quality Control

Batches of HDPE 30x30 vertical pipe clips are sampled for pull-out load testing, dimensional gauging and fatigue cycling before dispatch.

Applications

Vertical siphonic downpipes use the HDPE 30x30 vertical pipe clip for rigid support at every floor.
High-rise rainwater stacks rely on this siphonic drainage clip to keep 30x30 risers plumb.
Industrial buildings install the HDPE 30x30 vertical pipe clip where humidity corrodes metal clips.
Commercial towers choose this siphonic drainage clip for maintenance-free vertical pipe support.
