HDPE Butt Fusion Reducer Cross for Water

HDPE reducer cross manufactured from PE100 for four-way connections with reduced branch.

Extra Valuable Service
✧High Quality: ISO Certified Quality ✧Global Transportation Service
✧Free samples& Free Design ✧Full Satisfaction Guaranteed: 5-Year Guarantee

Category: HDPE Butt Fusion Fittings

HDPE Butt Fusion Fittings

Product Overview

HDPE reducer cross manufactured from PE100 for four-way connections with reduced branch. This HDPE butt fusion reducer cross intersects two lines and drops to a smaller diameter on the branch outlets in one molded body, eliminating extra reducer joints. The HDPE butt fusion reducer cross covers OD 90 - 315 mm in PN12.5 - PN16 ratings per ISO 4427.

Quick Information

Type: Reducer Cross
Material: HDPE PE100
Size: OD 90 - 315 mm
Pressure: PN16 / PN12.5
Standard: ISO 4427 / EN 12201
Stock: In stock

Specification Table

规格 dn-dn1	dn	dn1	L (mm)	H (mm)	SDR17	SDR13.6	SDR11
+90X63	90	63	240	75
+110X63	110	63	279	68
+110X75	110	75	279	75
+110X90	110	90	279	82
+160X63	160	63	329	67
+160X75	160	75	329	74
+160X90	160	90	329	82
+160X110	160	110	329	85
+200X110	200	110	379	85
+200X160	200	160	379	85
+225X110	225	110	415	86
+225X160	225	160	415	86
+225X200	225	200	415	91
+250X110	250	110	461	96
+250X160	250	160	461	96
+250X200	250	200	461	98
+315X110	315	110	543	91
+315X160	315	160	543	91
+315X200	315	200	543	96
+315X250	315	250	543	110
+355X200	355	200	485	120
+400X110	400	110	351	120
+400X200	400	200	439	120
+450X200	450	200	490	120
+450X315	450	315	605	130
+500X110	500	110	356	125
+500X160	500	160	406	125
+500X200	500	200	445	135
+500X250	500	250	495	135
+500X315	500	315	560	136
+500X400	500	400	644	136
+560X200	560	200	515	140
+560X315	560	315	625	140
+630X200	630	200	530	140
+630X315	630	315	660	140
+710X200	710	200	568	167
+710X315	710	315	681	167
+710X400	710	400	794	168

Key Features

Reduced Branch Outlets: The HDPE butt fusion reducer cross drops branch diameter in the same fitting, removing separate reducers from the junction.
Four-Way Intersection: One HDPE butt fusion reducer cross replaces a cross plus two reducers, cutting weld count and installation time.
PE100 High-Strength Material: Every HDPE butt fusion reducer cross is molded from virgin PE100 compound rated for a 50-year design life.
Leak-Free Fusion: All four ends of the HDPE butt fusion reducer cross weld with standard butt fusion machines for a monolithic intersection.
Rated PN12.5 - PN16: The HDPE butt fusion reducer cross matches common PE100 pipe classes from OD 90 to 315 mm.
Corrosion-Free Service: The HDPE butt fusion reducer cross never rusts or scales, keeping all four outlets at full bore for decades.

Production

Raw Material

The HDPE butt fusion reducer cross is molded from certified PE100 black compound with uniform carbon black dispersion, meeting ISO 4427 and EN 12201.

Molding Process

Injection molding forms the HDPE butt fusion reducer cross with multi-axis cores that shape the main run and reduced branches in one cycle, holding alignment within 0.1 mm.

Quality Control

Every HDPE butt fusion reducer cross batch is gauged for end diameter, branch alignment and wall thickness, then sampled for hydrostatic strength per ISO 1167.

Applications

Grid-network intersections use the HDPE butt fusion reducer cross where a main crosses and feeds smaller streets.
Irrigation block layouts rely on the HDPE butt fusion reducer cross to split mains into reduced laterals in both directions.
Industrial distribution racks install the HDPE butt fusion reducer cross for compact four-way reductions.
Building service manifolds choose the HDPE butt fusion reducer cross to branch reduced lines off a crossing main.
