Extra Valuable Service ✧High Quality: ISO certificated ✧Global Transportation Service ✧Free samples& Free Design ✧Full Satisfaction Guaranted: 5 Yeas
✦HDPE Pipes for Portable Water & Natural Gas 前面星号保留
HDPE pipe& fittings has proven to be excellent to a amount of other many materials as the way transporting and distributing potable drinking water and natural gas system. HDPE pipe’s lengthy lifespan and reduced maintenance costs, together with its’ ability to be installed with a selection of trench-less technologies make HDPE pipe obtaining the lowest lifetime cycle costs associated with any potable drinking water piping system and underground natural gas.
High Density Polyethylene (HDPE) Solid Wall Pipe systems have been worked for underground water supply since their introduction in the year 1955s. The plastics industry has taken great responsibility in making sure that the HDPE pipeline used do not adversely affect drinking water quality.
HDPE pipe is the future and the ideal piping solution for natural gas system. High-performance PE4710/PE100/PE100RC is a superior option as it offers weight and cost savings because of its higher Hydrostatic Design Basis (HDB) which results in a higher pressure rating, increased flow capacity, higher tensile strength and improved long-term performance without compromising the traditional MDPE PE2708/PE80 pipe benefits of flexibility, leak-free heat fusion joints, chemical resistance, and ease of installation.
✦Jointing methods of HDPE Pipes for Portable Water & Natural Gas that fit your multiple requirements 前面星号保留
We provide complete system solutions with engineer support based on years of experience in HDPE pipes and fittings projects worldwide. All pipes section are supplied with flanges connections and blind flanges to facilitate a quick assembly and increase the overall safety of your installation. To fit your unique projects requirements. Our HDPE pipes and fittings for Portable Water & Natural Gascan be jointed using several methods:
Electrofusion welding
Butt fusion welding
Socket fusion welding
Extrusion welding
Saddle welding
Flange connection
Quick fittings connection
✦Benefits of HDPE Pipe for Portable Water & Natural Gas
HDPE pipe is a type of plastic piping used in plumbing and natural gas system. They are often used for their resistance to corrosion and chemicals, as well as their durability.
Safety of potable water and long-term reliability
Resistance to corrosion, tuberculation, deposits
Flexibility to speed installations
Freeze-break resistance
Lightweight, easy to transport
Low scrap value, avoiding Jobsite theft
Durability and toughness to survive Jobsite installations
No flame used for joining, with many fitting and joining options
Recyclable, eco-friendly material
Heat fusible for virtually leak-free performance
HDPE Pipes for Portable Water & Natural Gas
HDPE Pipe for Gaseous Fuels and Natural Gas
✦Jointing methods that fit multiple requirements for HDPE Pipes for Portable Water & Natural Gas
We provide complete system solutions with engineer support based on 20 years of experience in HDPE pipes projects worldwide. All pipes section are supplied with flanges connections and blind flanges to facilitate a quick assembly and increase the overall safety of your installation. To fit your unique projects requirements. Our HDPE pipes and fittings for Portable Water & Natural Gas can be jointed using several methods:
Electrofusion welding
Butt fusion welding
Socket fusion welding
Quick fittings connection
Saddle welding
Flange connection
✦HDPE Fittings Manufacturerd and Supplied together with our HDPE Pipes
✦Specifications of High Density Polyethylene (HDPE) Pipes and Fittings for water ISO4427 Standard
ISO 4427-2: Plastics piping systems. Polyethylene pipes & fittings for water supply – Part 2: Pipes
EN 12201-2: Plastics piping systems for water supply – Polyethylene – Part 2: Pipes
EN 1555-2: Plastics piping systems for the supply of gaseous fuels – Polyethylene – Part 2: Pipes
ISO 4437-2: Plastics piping systems for the supply of gaseous fuels – Polyethylene – Part 2: Pipes
ISO Size and Dimension Data
Henan Bingo Pipeline ISO HDPE Series
Pressure Ratings are calculated using a 1,25 design coefficient (C) for MRS at 20°C as listed in PPI TR-4 for PE 100 materials. Pressure ratings are based on water applications. Temperature, Chemical, and Environmental use considerations may require use of additional design coefficients.
ISO 4427 Pipe Series
S 3.2
S 4
S 5
S 6,3
S 8
S 10
S 12,5
S 16
ASTM F714 DR
DR 7.4
DR 9
DR 11
DR 13.6
DR 17
DR 21
DR 26
DR 33
Nominal Pressure PE 100
PN = 25 bar
PN = 20 bar
PN = 16 bar
PN = 12,5 bar
PN = 10 bar
PN = 8 bar
PN = 6 bar
PN = 5 bar
Nominal Size DN (mm)
Equiv Size (in)
Min Wall (mm)
Average ID (mm)
Min Wall (mm)
Average ID (mm)
Min Wall (mm)
Average ID (mm)
Min Wall (mm)
Average ID (mm)
Min Wall (mm)
Average ID (mm)
Min Wall (mm)
Average ID (mm)
Min Wall (mm)
Average ID (mm)
Min Wall (mm)
Average ID (mm)
20
0.79
3.0
13.6
2.3
15.12
2.0
15.76
1.5
16.88
1.2
17.51
1.0
17.98
0.6
18.72
0.61
18.72
25
0.98
3.5
17.60
3.0
18.64
2.3
20.12
2.0
20.76
1.5
21.88
1.2
22.48
0.8
23.39
0.76
23.39
32
1.26
4.4
22.70
3.6
24.37
3.0
25.64
2.4
26.91
2.0
27.76
1.5
28.77
1.0
29.94
0.97
29.94
40
1.57
5.5
28.30
4.5
30.46
3.7
32.16
3.0
33.64
2.4
34.91
2.0
35.76
1.2
37.43
1.21
37.43
50
1.97
6.9
35.40
5.6
38.13
4.6
40.25
3.7
42.16
3.0
43.64
2.4
44.91
2.0
45.76
1.52
46.79
63
2.48
8.6
44.80
7.1
47.95
5.8
50.70
4.7
53.04
3.8
54.94
3.0
56.64
2.5
57.70
1.91
58.95
75
2.95
10.3
53.20
8.4
57.19
6.8
60.58
5.6
63.13
4.5
65.46
3.6
67.37
2.9
68.85
2.27
70.18
90
3.54
12.3
63.90
10.1
68.59
8.2
72.62
6.7
75.80
5.4
78.55
4.3
80.88
3.5
82.58
2.73
84.22
110
4.33
15.1
78.00
12.3
83.92
10.0
88.80
8.1
92.83
6.6
96.01
5.3
98.76
4.2
101.10
3.33
102.93
125
4.92
17.1
88.70
14.0
95.32
11.4
100.83
9.2
105.50
7.4
109.31
6.0
112.28
4.8
114.82
3.79
116.97
140
5.51
19.2
99.30
15.7
106.72
12.7
113.08
10.3
118.16
8.3
122.40
6.7
125.80
5.4
128.55
4.24
131.01
160
6.30
21.9
113.60
17.9
122.05
14.6
129.05
11.8
134.98
9.5
139.86
7.7
143.68
6.2
146.86
4.85
149.72
180
7.09
24.6
127.80
20.1
137.39
16.4
145.23
13.3
151.80
10.7
157.32
8.6
161.77
6.9
165.37
5.45
168.44
200
7.87
27.4
141.90
22.4
152.51
18.2
161.42
14.7
168.84
11.9
174.77
9.6
179.65
7.7
183.68
6.06
187.15
225
8.86
30.8
159.70
25.2
171.58
20.5
181.54
16.6
189.81
13.4
196.59
10.8
202.10
8.6
206.77
6.82
210.55
250
9.84
34.2
177.50
27.9
190.85
22.7
201.88
18.4
210.99
14.8
218.62
11.9
224.77
9.6
229.65
7.58
233.94
280
11.02
38.3
198.80
31.3
213.64
25.4
226.15
20.6
236.33
16.6
244.81
13.4
251.59
10.7
257.32
8.48
262.01
315
12.40
43.1
223.60
35.2
240.38
28.6
254.37
23.2
265.82
18.7
275.36
15.0
283.20
12.1
289.35
9.70
294.44
355
13.98
48.5
252.20
39.7
270.84
32.2
286.74
26.1
299.67
21.1
310.27
16.9
319.17
13.6
326.17
10.90
331.89
400
15.75
54.7
284.00
44.7
305.24
36.3
323.04
29.4
337.67
23.7
349.76
19.1
359.51
15.3
367.56
12.30
373.92
450
17.72
61.5
319.60
50.3
343.36
40.9
363.29
33.1
379.83
26.7
393.40
21.5
404.42
17.2
413.54
13.80
420.74
500
19.69
67.6
356.70
55.8
381.70
45.4
403.75
36.8
421.98
29.7
437.04
23.9
449.33
19.1
459.51
15.30
467.56
560
22.05
75.7
399.50
62.5
427.50
50.8
452.30
41.2
472.66
33.2
489.62
26.7
503.40
21.4
514.63
17.20
523.54
630
24.80
85.1
449.60
70.3
480.96
57.2
508.74
46.3
531.84
37.4
550.71
30.0
566.40
24.1
578.91
19.30
589.08
710
27.95
95.9
506.70
79.3
541.88
64.5
573.26
52.2
599.34
42.1
620.75
33.9
638.13
27.2
652.34
21.80
663.78
800
31.50
108.1
583.8
89.3
610.68
72.6
646.09
58.8
675.34
47.4
699.51
38.1
719.23
30.6
735.13
24.50
748.06
900
35.43
126.62
646.76
100.0
700.00
81.7
726.80
66.2
759.66
53.3
787.00
42.9
809.05
34.4
827.07
27.60
841.49
1000
39.37
135.14
729.72
111.12
777.76
90.2
808.78
72.5
846.30
59.3
874.28
47.7
898.88
38.2
919.02
30.60
935.13
1200
47.24
162.16
875.68
133.34
933.32
109.1
981.82
88.2
1013.02
67.9
1056.05
57.2
1078.74
45.9
1102.69
36.70
1122.20
1400
55.12
189.19
1021.62
155.56
1088.88
127.3
1145.46
102.9
1181.85
82.4
1225.31
66.7
1258.60
53.5
1286.58
42.90
1309.05
This product flyer is intended for reference purposes. It should not be used in place of the advice from a licensed Professional Engineer. Nominal pressure (PN) is based on C = 1,25 and an operating temperature of 20°C. Weight is calculated using DN and Minimum wall plus 6% for use in estimating fluid flow. Actual ID will vary. When designing components to fit the pipe ID, refer to pipe dimensions and tolerances in the applicable pipe manufacturing specification. To obtain pressure in psi, multiply bar by 14.5 (1 bar ≈ 14.5 psi). Additional information is available at www.bingopipes.com.
Other specifications have not been shown on our dimension chart, please CONTACT US for more information
